Appendix: Explanation of devices supporting USB-C (DP Alt Mode)

Including but not limited to the following models, continuously updated...

Models supported by game consoles and gaming consoles

GPD
Nintendo
Valve
Sony

Microsoft

WIN 3 / 4 / 2023 / 2024 | WIN Mini / 2024 | XP / XP Plus
Switch | Switch OLED
Steam Deck
PS4 Pro | PS5

Xbox Series X | Xbox Series S

Supported laptop models

GPD
Huawei
Honor
Apple
Xiaomi
Redmi
Lenovo
ASUS
Samsung
Razer
HP
Dell
Microsoft
Google

Android tablet supported models

Huawei
Apple
Samsung

M6 10.8-inch | MatePad 10.8-inch | MatePad Pro
iPad Pro 2018 | iPad Pro 2020 | iPad Air4
Galaxy Tab S4 / S5e / S6 / S7 / S7+

Supported models for smartphones

PC desktop mode (touch-enabled when connected to a monitor, similar to the Windows interface)

Huawei
Honor
Samsung
Smartisan

No PC desktop mode (when connected to a monitor, mostly non-touch and mirroring the phone's content)

Apple
Xiaomi
Black Shark
OnePlus
ASUS
Razer
Sony
Other

AMD Ryzen™ AI 9 HX 370

Your Key to Unlock Magical AI Experiences

GPD DUO Dual-Screen

13.3-inch Dual Screen Productivity Laptop for Engineers

Ultra-Portable | Versatile Ports | Integrated Design | 60W TDP

Max Performance | Multi-Modal | AI PC

Aurora OLED Full Screen

Radiant Display

Aurora OLED Full Screen: Radiant Display. Outstanding color performance and stunning contrast bring an unprecedented visual feast. Every pixel shines to create delicate and vivid images with vibrant, full-color details, clear details, and natural color transitions.

SCREEN

Visual Enjoyment

Professional-Grade Display

Vivid Colors, Comfortable
Designed for Work, and Breath Taking

100% Adobe RGB color space, beloved by designers and artists alike. Approaching the color range used in traditional printing and photography fields, offering a wide gamut panel and highly nuanced colors with higher color accuracy and precision.

100%

Adobe RGB

133%

sRGB

Supports Stylus Pen

4096 Levels of Pressure Sensitivity

Photoshop

illustrator

Coreldraw

Designer

2.8K Dual OLED Screen, Every Ray of Light and Shadow, Finely Detailed and Realistic to the Point of Astonishment

The high contrast and self-illuminating pixel design of OLED can present you with true blacks close to 0 nits and bright whites. With a 1 ms rapid response time, it provides smoother and more delicate visual effects for watching movies and playing games.

Near 0 nits

Pure Black Experience

GTG : 1 ms

E-sports Level Display Rate

1,000,000 : 1

Ultra-High Contrast Ratio

500 cd/m²

Peak Brightness

10.7 Billion Colors, Ultra-wide Color Gamut, Amazing Visual Experience

Each unit is individually calibrated before leaving the factory, creating exclusive ICC profiles for a professional movie-grade color accuracy experience. Together, they produce a dazzling and lifelike visual feast.

10bit Color Depth

10.7 Billion Colors

DCI-P3 : 100%

Cinema-Grade WCG

NTSC : 96%

Beyond "NTSC" Standard

Delta E < 1

Professional Monitor Calibration

13.3-inch Full-screen

Ultra-Narrow Bezels

Screen-to-body ratio as high as 90%, 16:10 golden ratio, fully laminated mirror screen, LTPS technology + Corning Gorilla Glass.

Screen-To-Body Ratio

90%

Mirror Screen

Corning Gorilla Glass

LTPS Technology

Fully Laminated

Dual Screens Provide an 18-inch Display Area, Expanding Your Visual Experience

The secondary screen can mirror the main screen, serve as an extended display, or show content independently. Enjoy a larger field of view and expanded visual space!

Duplicate

Extend

Dual Screens

18 Inches

Second Screen Only

AMD Ryzen™ AI 9 HX 370

Breaking Limits, Offering Exceptional Performance

Utilizing advanced 4nm manufacturing process, ZEN 5 + RDNA 3.5 + XDNA 2 architecture, experience cutting-edge artificial intelligence (AI) technology, accelerate multitasking, boost productivity, foster collaboration, and enhance efficiency.

AMD Ryzen™ AI 9 HX 370

12 Cores

24 Threads

5.1 GHz

Max. Boost Clock

36.75 MB

Full Cache

80 TOPS

TPP

AMD Radeon™ 890M

16 CU

1024 SU

2.9 GHz

Boost Clock

11.88 TFLOPS

FP32 (half)

23.76 TFLOPS

FP16 (half)

Strix Point

Zen 5 Architecture

TSMC 4nm

Manufacturing Process

35~60W

Configurable TDP

CPU-Z Single-Core and Multi-Core Benchmark:

Single-Core

Multi-Core

816

509

9126

8899

AMD Ryzen™ AI 9 HX 370 (45W)

Intel® Core™ i9-7980XE Extreme Edition (165W)

AMD Ryzen™ AI 9 HX 370 (45W)

Intel® Core™ i9-7980XE Extreme Edition (165W)

FP64（GFlop/s）

80 TOPS

38 TOPS

36 TOPS

556.8

169.9

AMD Ryzen™ AI 9 HX 370

AMD Ryzen™ 7 8845HS

Intel® Core™ Ultra 9 processor 185H

Overall APU Computing Power Comparison:

Time Spy Score Comparison, 890M Integrated Graphics Outperforms NVIDIA GeForce RTX 2050 (Mobile)

AMD Radeon 890M integrated graphics, based on the all-new RDNA 3.5 architecture, integrates 16 CUs with 1024 sp, delivering a 33% improvement in specifications compared to the previous generation, resulting in a 36% increase in gaming performance! Combined with LPDDR5x 7500 MT/s memory, the graphics memory bandwidth has also been enhanced.

3783

3769

3218

3118

2945

2791

GPD DUO (890M) 54W

NVIDIA GeForce RTX 2050 (Mobile) 45W

GPD WIN Max 2 (780M) 单翼 Review, 72W

GeForce GTX 1650 Ti Max-Q (Mobile) 50W

GeForce GTX 1650 Max-Q (Mobile) 45W

7940HS & Radeon 780M (iGPU) 54W

3DMark - Time Spy Graphics Score Somparison:

Brand-new XDNA 2 Architecture NPU, 50 TOPS Strongest AI Accelerator

The brand-new AMD XDNA 2 architecture NPU is 3 times more powerful than the previous generation NPU, reaching 50 TOPS. Combined with the CPU and GPU, the total computing power is as high as 80 TOPS, far exceeding the 40 TOPS computing power standard of AI PCs. It improves computing efficiency and reduces overall power consumption, making local AI computing tasks such as AI matting faster and more efficient.

AMD Ryzen™ AI 9 HX 370

Qualcomm Snapdragon X Elite

NPU Computing Power Comparison:

50 TOPS

45 TOPS

38 TOPS

Apple M4（10-CPU）

With 64GB of LPDDR5x 7500MT/s Memory, There is no Need to Worry About Memory Overflow During Gaming

The GPD DUO utilizes LPDDR5x 7500MT/s memory, available in three capacities: 16GB, 32GB, and 64GB. Up to 16GB of this memory can be allocated to VRAM, allowing AI applications that require large VRAM to fully perform. While gaming, there's no need to worry about memory overflow, ensuring smooth gameplay.

Dual Fans, Dual Heat Pipes, High Perfomance Cooling System, Releasing Maximum Performance With 60W TDP

Featuring a dual heat pipe distribution design paired with dual fans, with a high-volume turbo fan for comprehensive cooling, ensuring sustained coolness and unleashing ultimate performance for you!

Control CPU Cooling

FAN 1

Motherboard and Other

FAN 2

2 M.2 NVMe Ports, Unlimited Storage

Built-in 2 M.2 NVMe protocol ports, both compliant with PCIe 4.0 × 4 bus specifications, support 2280 single-sided SSDs. Currently expandable up to a maximum of 16TB (8TB + 8TB) capacity, without theorical limit.

Exclusive Oculink Port for Expanding External Graphics Cards, Creating an Exceptional "AI PC"

Integrated Oculink (SFF-8612) female port, providing PCIe direct connection, 63Gbps effective bandwidth, supports devices like GPD G1 eGFX, delivering a total computing power of 66 TOPS. Empowering outstanding performance for personal AI processing and creating the ultimate gaming experience for gamers on mobile devices.

Multiple Screens, Run Multiple OS, A Developer's Dreamed Device

The powerful computing power of DUO + G1, combined with virtual machines, makes multi-screen, multi-system setups a dream platform for developers. Open multiple IDEs across different systems with ease, and effortlessly build cross-platform applications.

Support for Multiple Screens, Run Multiple OS Simultaneously

Please note:

1. The virtual machine mentioned on this page is VMware Workstation Pro v17.5.1. Other similar virtual machines include Oracle VM VirtualBox, Microsoft Hyper-V, and Kernel-based Virtual Machine, with largely similar functions.
2. Running multiple virtual machine systems requires at least 64GB or more of memory. To enhance the smoothness of virtual machine systems under VMware Workstation Pro, select "Exclusive Mode" in full-screen status, allowing shared physical hardware.
3. To use multiple monitors for a single virtual machine, refer to: vmware Docs
4. To use multiple monitors for multiple virtual machines, refer to: vmware Docs

60Hz

Refresh Rate

13.3-inch OLED Aurora Screen × 2

Dual Screens up to 18 Inches

255 PPI

Pixel Density (RGB)

16 : 10

Aspect Ratio

2880 × 1800

WQXGA+ Resolution

10-Point Touch

Supports Dual-screen Touch

80 TOPS

GPD DUO

CPU + GPU + NPU

28 TOPS

GPD G1

64 AI Accelerators

108 TOPS

TPP

GPD DUO + GPD G1

Four-screen Collaboration, A Powerful Tool for Financial Investors

Extra outputs allowing expandable to 2 additional screens through the body. Four-screen collaboration is a powerful tool for investors, providing instant stock quotes, real-time data, and financial news at a glance. See the big picture, seize every investment opportunity, and maximize returns.

The Secondary Screen Rotates 360 Degrees to Become A Tablet. In Tablet Mode, You Can Control Any OS, Offering an Experience Like Never Before

If you have never experienced a Linux tablet or MacOS tablet, the GPD DUO will satisfy you. The secondary screen can rotate 360 degrees to instantly transform into a tablet. Run any system in a virtual machine, use full-screen "Exclusive Mode" to share physical hardware, and experience the most powerful tablet ever.

AMOLED 2 360° Flip

Experience Any OS

Supports Touch Screen

Vmware Auto-Adaptation

Supports Stylus With 4096 Levels of Pressure-sensitive, Write and Draw in Tablet Mode, Limitless Creativity

Supports dual-screen handwriting, Supports active stylus input based on Microsoft MPP protocol, Compatible with Surface Pen stylus 4096 levels of pressure sensitivity, Original handwriting capture Ideal for inspiration, on-the-go notes, creative drawing with artistic precision, Annotations and signatures done in a single step.

4096-level Pressure

Original Handwriting

Connect Phone to Secondary Screen Via Single Cable, Instantly Transforms to PC. Work Effortlessly on Large Screen, no Eye Strain

Is your phone's screen too small for office work? Connect to GPD DUO's USB-C (secondary screen port), and it instantly transforms into a tablet. Working on the go has never been this simple!

Computer Mode

PC Desktop, Full-Screen Display

No Computer Mode

Desktop Rotates With the Phone

Note:

1. The USB-C cable used for connection must support full functionality. When connecting a phone with TV-out or DP ALT Mode, the phone will output different desktops to AMOLED 2 depending on whether it supports computer mode.
2. TV-out is essentially a packaged concept introduced by Qualcomm after the Snapdragon 835 SoC, fundamentally based on DP 1.4 technology.
3. Not all phones support TV-out or DP ALT Mode. Even phones that support TV-out or DP ALT Mode might not have a computer mode. Refer to the incomplete list at the bottom of this page for supported devices. Some Android phones or tablets require selecting mirror or extend mode for output; choose according to your actual needs.
4. AMOLED 2 does not provide power to third-party devices. When the phone is connected while the host is powered on, AMOLED 2 is powered by the host. When the host is powered off, AMOLED 2 is powered by the phone.
5. In the powered-off state of the GPD DUO, not all phones can drive and light up AMOLED 2. Whether it can be lit up depends on the power supply capability of the phone's USB-C.

The Secondary Screen Has an Independent Switch and Can be Turned Off Using A Key Combination

When the secondary screen is idle, the Fn+F3 key combination can turn it off, saving power and offering simple convenience.

Fn+F3

Independent Physical Buttons Make Adjusting the Secondary Screen's Brightness Easy and Convenient

The secondary screen is equipped with dedicated brightness adjustment keys, allowing for easy control of screen brightness with a single finger in tablet mode.

Eliminate Need for Separate Portable Screen; Connect Game Consoles to Secondary Screen for Gaming

Work and play without compromise! During breaks, connect your handheld console directly to the secondary screen of GPD DUO that you carry with you, and enjoy gaming on a larger screen! Supported by GPD WIN 3 and most of the newest handheld devices!

More Supported Products:

Note:

Game consoles typically use HDMI ports. When connecting to the secondary screen, you'll need to use an HDMI to Type-C (supporting DP signal) video cable or adapter to convert the HDMI input signal to DP output signal.

Audio Technology

Experience True Surround Sound

Built-in with two AAC top stereo linear speakers, both speakers and headphones support DTS: X Ultra audio technology, capable of simulating physical 7.1 channels!

Easily Copy Image Data Anytime, A Photographer's Boon!

The device is equipped with an SD card slot, supporting SDHC, SDXC, microSDHC, and microSDXC memory cards with UHS-II high-speed bus port. It supports V90 video speed class, with theoretical peak read/write speeds up to 312MB/s.

Dedicated 2.5K High-definition Camera for Remote Video Communication, Providing Convenience and Efficiency

Built-in wide-angle camera, whether for remote work, video conferencing, or video calls with friends and family, it meets all your needs!

2592 × 1944

Automatic Framing

Video Brightness

System Control

AI Smart Office

Real-Time Transcription of Subtitles

Clearer Audio And Visuals

AI Voice and Image Intelligent Noise Reduction

Easily Handle Various Network Environments, Transferring A 1GB File in Just 3 Seconds

Built-in 2.5G Ethernet port with RJ45 connector for faster and more stable internet browsing, gaming, video streaming, and file transfers. Wi-Fi 6E wireless card ensures seamless connectivity across various network environments. Bluetooth 5.3 supports connectivity with up to 255 devices!

Wi-Fi 6E

Bluetooth 5.3

2.5Gb Ethernet Port

80Wh Ultra-large Capacity Battery, Supports Continuous 1080P Video Playback for 14 Hours

Battery optimized for extended performance, providing long-lasting endurance without frequent charging. Offers stable and reliable power support for uninterrupted creativity and entertainment.

100W Super Fast Charging With PD Charging Protocol, Charges Up to 50% in Just 30 Minutes

PD 3.0 fast charging provides you with a fast and reliable charging experience. When the device is powered off, it charges up to 50% in 30 minutes, ensuring your AI PC stays efficiently powered for optimal performance.

Rich Ports, High-speed Transfer, Meeting More Scenarios

HDMI 2.1

Air Outlet

Oculink (SFF-8612)

Air Outlet

RJ45 Port

Power Button / Fingerprint Unlock

USB A 3.2 Gen1

Speaker Port

Reset Button

USB4

Charge Indicator

Full-Featured Type-C

SD Card Slot

Earphone / Microphone Ports

Type C (DP ALT)

AMOLED 2 Brightness Control Keys

Speaker Port

Roughly the Size of an A4 Paper, it's Portable Enough to Carry With You for Work Anytime

GPD DUO: 297 × 209.65 mm

A4 Paper: 297 × 210 mm

Metal Body, Lightweight and Portable, Durable and High-end Craftsmanship Design

The body is crafted from aluminum alloy, ultra-thin and lightweight, featuring powerful performance for immersive gaming and effortless creativity. Continuing the classic black design, it exudes a sense of calmness and nobility, enhancing the mysterious appeal with its appearance and touch.

Thickness: ≈ 24mm

Weight: ≈ 2200g

Portable

Ideal for O&M

Full-size Backlit Keyboard

Precision Touchpad (PTP Mode)

Standard chiclet keyboard, island-style layout, full QWERTY keyboard design with white backlighting for effortless use in low-light conditions. Precision touchpad (PTP mode) supports left and right button vibration feedback, ensuring consistent touch sensitivity across all areas!

Key Travel of 1.3mm

Integrated Fingerprint Power Button

Supports Vibration Feedback

2.8K Resolution, Dual Touch, Dual Stylus Support

Dual 13.3-inch OLED

Aurora Full Screens

Connect to eGFX

Powerful Performance
Comparable to Gaming Laptops

Connect to AMOLED 2

Mobile Phone, Handheld Gaming Console, Gaming Console

AMD Ryzen™

AI 9 HX 370

Outstanding Computing Power, Intelligent Processing Engine

64GB LPDDR5x

2TB 2280 SSD

Dual M.2 NVMe Ports

80Wh Battery

14 Hours Long Battery Life with 100W PD Fast Charging

GPD DUO

Screen: AMOLED × 2，13.3 inches, support active capacitive stylus

CPU: AMD Ryzen™ AI 9 HX 370

GPU: AMD Radeon™ 890M

DDR: 16GB / 32GB / 64GB，LPDDR5x 7500 MT/s

SSD: 512GB / 1TB / 2TB × 1

M.2: NVMe 1.4 × 2

Oculink SFF-8612: × 1

USB4: × 1

USB-C (Full-Featured) : × 1

USB-C (Only DP ALT Mode) : × 1

USB-A : × 2

HDMI (2.1) : × 1

RJ45 (2.5Gb) : × 1

SD Slot (4.0) : × 1

Thermal: Dual Fans, Dual Heat Pipes

Wi-Fi: Wi-Fi 6E

Bluetooth: BT 5.3

Battery: 80Wh

Size: 297 × 209.65 × 23.8 (mm)

Weight: 2200g

More >>

Correct Way to Use GPD DUO

When the secondary screen is folded under the primary screen, after opening the screens, the maximum opening angle of the primary screen is 135°, and the secondary screen can rotate 360° to the back of the primary screen.

ꂃ ꁹ

The Main Screen Features a Precision Hinge Stand For Stability. When Retracted, Neodymium Magnets Hold it in Place

The stand is made of ABS + UV + semi-organic silicone leather + precision metal plate. When the main screen is opened to its maximum 135-degree angle, the stand forms a 45-degree angle with the main screen, taking up minimal space. This design minimizes screen wobble during touch operations on the secondary screen, providing stronger support.
