Basic Information
Launch Date
Product Positioning
Operating System
12 / 2024
Handheld Game Console
Pre-installed with Windows 11 Home 24H2


Tech Specs
Display
Touch Panel
Screen Type
Screen Size
Aspect Ratio
Screen Resolution
Pixels Per Inch
Supports
Corning Gorilla Glass 5，H-IPS Technology
6 Inches, Native Landscape Mode, DC Dimming
16：9
1920 × 1080, 1280 × 720, Image resolution: 40Hz & 60Hz
368 PPI


CPU
Product model
Architecture
# of CPU Cores / # of Threads
Base Clock
Max. Boost Clock
AI Performance
Total Processor Performance
Total Cache
Process Size
TDP

AMD Ryzen™ AI 9 HX 370
Zen 5 + Zen 5C（Strix Point）
12C / 24T
2.0 GHz
5.1 GHz
50 TOPS
80 TOPS
36.75 MB
4nm
15W-35W


AMD Ryzen 7 8840U
Zen 4（Hawk Point）
8C / 16T
3.3 GHz
5.1 GHz
16 TOPS
38 TOPS
24.5 MB
4nm
15W-35W


GPU
Processor Graphics
Graphics Frequency
Compute Units
Shading Units
Floating-point Performance


Pixel Rate
Texture Rate


AMD Radeon™ 890M
2900 MHz
16 CU
1024
23.76 TFLOPS（FP16）
11.88 TFLOPS（FP32）
742.4 GFLOPS（FP64）
92.80 GPixel/s
185.6 GTexel/s


AMD Radeon™ 780M
2700 MHz
12CU
768
17.82 TFlops（FP16）
8.92 TFlops（FP32）
556.8 GFlops（FP64）
92.80 GPixel/s
139.2 GTexel/s


Storage

Memory
Memory Types
Memory Channel
Hard Disk Type
Hard Disk Port
Supported Specifications
Standard Capacity
Bus Specification
Transfer Protocol


32GB
LPDDR5x 7500 MT/s
Dual Channe
M.2 SSD
M.2（Socket 3）× 1
M.2 NVMe 2280 × 1
2TB × 1
PCIe 4.0 × 4
NVMe 1.3 / 1.4


32GB
LPDDR5x 7500 MT/s
Dual Channe
M.2 SSD
M.2（Socket 3）× 1
M.2 NVMe 2280 × 1
1TB × 1
PCIe 4.0 × 4
NVMe 1.3 / 1.4


Multimedia Support


Audio System
Loudspeakers
Microphone

Built-in Sound Chip + Intelligent Amplifier That Features High Energy Efficiency, High PSRR and Low Noise
Built-in Dual Speakers
Built-in Microphone


Network Communications

4G LTE Module









Wi-Fi
MU-MIMO
Bluetooth

Back-mount Module, Selectable
Type of SIM Card: Nano-SIM, Single
4G Network：TD-LTE，FDD-LTE
3G Network：WCDMA/TD-SCDMA/CDMA
2G Network：GSM
"Frequency Band：
LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28
LTE-TDD: B38/B39/B40/B41
UMTS: B1/B2/B4/B5/B6/B8/B9
GSM: B2/B3/B5/B8"
Wi-Fi 6E(802.11ax) 2×2
Support
BT5.3


I/O Ports

Video / Data / Charging





microSDXC Slot






Ethernet Ports
Audio Port
BIOS Reset Port

USB4, 40Gbps (Full Speed) × 1
USB 3.2 Gen 2 Type-C Full-featured, 10Gbps × 1
USB 3.2 Gen 2 Type-C Charging Only (Provided By The Dock) × 1
Oculink (SFF-8612) female port with a bandwidth of 63Gbps and a throughput of up to 7.877GB/s × 1
USB 3.2 Gen 2 Type-A, 10Gbps (Provided By The Dock) × 3
HDMI 2.0 (Provided By The Dock) × 1
Bus Port: UHS-I
Speed Class: Class 10
Ultra High Speed: U3
Video Speed Class: V30
Application Performance Class: A2
Read/Write: 160MB/s, 90MB/s
Maximum Capacity: 2TB
RJ45 (Provided By The Dock) × 1
3.5mm Headphone/Microphone Combo Port, Compatible With Apple Headphones (US Specification) × 1
Supports



I/O Device

Keyboard
Mouse

Fingerprint Recognition
Joystick
D-Pad
Game Function Buttons
Game Accessories Buttons
Handle Vibration
Dorsal Key
Other Keys
Sensor
Speaker
Indicator Lamp


QWERTY Full Keyboard Design, Scissor-Switch Keys, White Backlight, And Combination Keys For On/Off Function
Mouse 1: Right Joystick Simulates Mouse, Requires Switching Between "Gamepad/Mouse" Mode
Mouse 2: Optical Finger Mouse With Support For Click Confirmation Via Pressure
Yes
ALPS OEM Dual 3D Joysticks With Native Support For L3/R3 Via Downward Press
Siamese Cross Key
ABXY、△○×□ Double Character Print, Select, Start, Xbox Controller Home
L1/R1 Feature Rainbow Lighting Design, While L2/R2 Are Linear Analog Buttons
Dual Vibration Motors, Software Controlled, Capable Of: Turning Off, Weak Vibration, Strong Vibration
Two Back Buttons, Mappable And Programmable
Volume +/- Buttons, Power Button, Gamepad/Mouse Mode Switch
6-axis Design: 3-axis G-sensor, 3-axis Gyro
2 Pcs
Charging Indicator, Running Indicator


Battery

Battery Type
Battery Capacity
Battery Life

Li-polymer
45.62Wh
2 Hours Of Heavy Use, 3-6 Hours Of Moderate Use, 10 Hours Of Light Use, Depending On The Specific Environment Of Use

Appearance


Net Weight
Length
Shell Material
Shell Color
Thermal Design

598g
220×92×28mm
LG-DOW 121H Aviation ABS, UL94-V0, Magnesium Alloy
Black
Active Thermal Dissipation, Large Fan, Double Thick-walled Heat Pipes


Accessories



GPD WIN 4 (2025) × 1
65W Power Adapter (20V==3.25A, 15V==3A) × 1
Warranty Card × 1
Product Manual × 1


Warranty Information


Warranty Policy
Warranty Time
Official hotline
Chinese Website
English Website

Global Warranty
Device 1 year, Charger 1 year
+ 86 755 86572275
www.Softwincn.com
www.Gpd.hk
